Mission

Dimatra is always aware of the needs for the converting machinery market, in order to assist thier clients fast and efficiently for either non-woven, plastic film (flexible packaging) or paper projects; by fulfilling every functional characteristic they´re looking for.

Vision

In Dimatra, they work hard to be known as a state of the art technology company. They have a highly motivated staff that designs, manufactures, and offers our clients the best quality.

DESIGN AND MANUFACTURE OF CONVERTING MACHINES

Dimatra has been consolidated as a proudly Mexican Company that has proven to be competitive for the performance of our machines in the Converting Industry of: nonwoven, paper and plastic films (flexible plastic packaging), with high quality standards.

They have the best infrastructure for the design and development of our machines, as well as a great team of engineers and technicians who are continuously trained to achieve our goals.

Every design in Dimatra is done with a 3D software to guarantee the best quality.



PAPER MACHINERY




Big Rolls Slitter Rewinder

Machine designed to slit and rewind different materials, such as paper, nonwoven and filter paper.

Options:
Shaft less unwinder, peripheral band on the winder, guiding system, trim extraction system, unloading table and curved rolls system for material separation.
Technical characteristics:
  • Unwinder diameter : 1,600 mm (63")
  • Standard widths : 1,500 mm (59") - 2,500 mm (98")
  • Maximum speed: 350 m/min (1,148 ft. /min)
  • Rewinder diameter: 1,600 mm (63")

Slitter Rewinder Small Rolls (Semiautomatic)

This machine can slit and rewind paper rolls for point sale (cash register, ATM, portable printer, adding machine) rolls for graphics printing, tickets fax, and general printers. It can work with either one or two layers

Options:
  • Trimmer
  • Plastic core feeder
  • Separator for finished rolls
  • Flattening press for finished rolls
  • Storage table for finished rolls
  • Flexo printing head
Technical characteristics:
  • Maximum width 1 layer: 750 mm (30")- 1100 mm (39")- 1350 mm (53")
  • Maximum diameter unwinder : 1,200 mm (47.24")
  • Maximum diameter rewinder: 300 mm (11.81")
  • Maximum speed : 350 m/min (1,155 ft./min)
  • Cycle time rolls 40 m/20.1 seg (131 ft./20.1 seg)
SEMIAUTOMATIC SR MACHINE 1100MM WITH END OF LINE

This machine can slit and rewind paper rolls for point of sale (cash register, ATM portable printer, adding machine) rolls for graphics printing, tickets, fax and general printers. It can work with either one or two layers.

Options:
  • Trimmer
  • Plastic core feeder
  • Separator for finished rolls
  • Flattening press for finished rolls
  • Storage table for finished rolls
  • Flexo printing head
Technical characteristics:
  • Maximum width 1 layer: 750 mm (30") - 1100 mm (39")- 1350 mm (53")
  • Maximum diameter unwinder : 1,200 mm (47.24")
  • Maximum diameter rewinder: 300 mm (11.81")
  • Maximum speed : 350 m/min (1,155 ft./min)
  • Cycle time rolls 40 m/20.1 seg (131 ft./20.1 seg)
SLITTER REWINDER SMALL ROLLS (MANUAL)

Machine designed to cut and rewind paper rolls for points of sale (register machines, automatic cashiers, portable printers, etc.), rolls for graphic impressions, tickets, fax and general use printers. Machine for 1 or 2 feeding rolls.

Options:
  • Edge trimmer
  • End of roll marking system
  • automatic cutting and treading
Technical characteristics:
  • Maximum width 1 layer : 1100 mm (39")
  • Maximum diameter unwinder : 1,100 mm (43")
  • Maximum diameter rewinder: 350 mm (14")
  • Maximum speed : 250 m/min (820 ft./min)
  • Productivity: 4,400 rolls per shift

TURRET REWINDER

High productivity machine because of its turret to rewind paper (big format printer rolls) and nonwoven doesn't need shaft in the rewinding section.

Options:
  • Edge trimmer
  • Edge trimmer
  • Guiding system
  • Shaft less unwinder.
Technical characteristics:
  • Maximum unwinder diameter : 1,200 mm (47")
  • Standard width : 1,000 mm (39") - 2,100 mm (83")
  • Maximum speed : 200 m/min (660 ft. /min)
  • Maximum finished rolls diameter: 450 mm (18")

FULLY EQUIPIED DUPLEX SLITTER REWINDER

This machine cuts and rewinds plastic film and laminated material. It produces excellent finished rolls. F support for the extraction of rolls with a 90° twist. Shaft less unwinder. Optional: - core positioning system with laser; - roll ejection system, - differential shafts.

Materials:
*Cellophane *PET *PE *PVC *BOPP *BOPA *LAMINATED MATERIAL *CPP
Technical characteristics:
  • Unwinder diameter :1, 000 mm (39")
  • Maximum width: 1,000 mm (39") – 1,300 mm (51") – 1600 mm (62")
  • Rewinding diameter: 800 mm (31")
  • Speed: 600 m/min (1,968 ft./min)


Converting MACHINERY




ECO-DUPLEX SLITTER REWINDER

This machine has been specially designed for those converters who need low production at low price. Excellent performance and easy to operate. Produces excellent quality of slitted rolls.

This machine runs with:
*Cellophane *PET *PE *PVC *BOPP *BOPA *laminated products *CPP *Label.
Technical characteristics:
  • Unwinding diameter: 700mm (27.5")
  • Rewinding diameter : 450 mm (17.7")
  • Material width: 1,300 mm (51")
  • Operating speed: 200 m/min (656 ft./min)

COMPACT DUPLEX SLITTER REWINDER

This machine cuts and rewinds plastic film and laminated material. It produces excellent finished rolls. differential shafts. control system and aligning system. Tension control by ultrasonic diameter sensor and vector motors.

This machine runs with:
*Cellophane *PET *PE *PVC *BOPP *Laminated material *label
Technical characteristics:
  • Unwinding diameter: 1,000mm (39")
  • Rewinding diameter : 600 mm (23")
  • Material width: 1,300 mm (51")
  • Operating speed: 500 m/min (1,640 ft....../min)

FULLY EQUIPIED DUPLEX SLITTER REWINDER

This machine cuts and rewinds plastic film and laminated material . It produces excellent finished rolls. Includes F support for the extraction of rolls with a 90° twist. Shaft less unwinder. Optional: - core positioning system with laser; - roll ejection system , - differential shafts.

This machine runs with:
*Cellophane *PET *PE *PVC *BOPP *BOPA *LAMINATED MATERIAL
Technical characteristics:
  • Unwinder diameter :1,000 mm (39")
  • Maximum width:1,000 mm (39") – 1,300 mm (51") – 1,600mm (62")
  • Rewinding diameter: 800mm (31")
  • Speed: 600m/min (1,968 ft./min)

TURRET TYPE DUPLEX SLITTER REWINDER COMPACT

Excellent performance compact machine. Easy to operate. Specially designed for those converters who need high production and time optimization. Produces excellent quality of slitted rolls.

This machine runs with:
*Cellophane *PET *PE *PVC *BOPP *Laminated material *label
Optional:
Shear-cut system, laser core-positioning system, finished-roll ejection system, differential shafts in different diameters, lifting table system at unwinder to load the roll (patented system).
Technical characteristics:
  • Unwinding diameter: 1,000 mm (39")
  • Rewinding diameter: 600 mm(23")
  • Standard widths: 1,000 mm (39") – 1,300 mm (51") – 1,600 mm (62")
  • Speed: 500 m/min (1,640 ft./min)

INSPECTION MACHINE WIDE FORMAT

Rewinder for big rolls designed to work with a wide category of materials. This machine allows the user to recover rolls with an effective method. It allows the operator to remove defective material, adjust the tension and align the material.

Process:
Shaft less central unwinder, Shaft less central Rewinder. Inspection table for material inspection, Rewind with taper tension, Alignment system, Reversible machine.
Optional:
Trimming system and trim extraction system, different core ID's, inspecting system with video camera or with stroboscope
Technical characteristics:
  • Maximum roll´s diameter : 1,000mm(40")
  • Standard width:1,300mm(51") - 1,600mm(63")
  • Rewinding speed: 350m/min (1,148 ft./min)
  • Inspection speed: 200m/min (656 ft./min)
  • Maximum roll´s weight: 800kg (1,770 pounds)

INSPECTION MACHINE FOR PLASTIC FILM ROLLS AND SHRINKING SLEEVES

This is a rewinder to inspect printed rolls and shrinking sleeves such as PVC, PET, PETG, OPS & PLA. Reversible machine.

Optional
Trimming system, edge suction, chucks for different diameter cores (3") and inspection system through a video camera or stroboscope.
Technical characteristics:
  • Maximum width at unwinding: 600 mm (23")
  • Maximum diameter at unwinding: 600 mm (23")
  • Maximum width at rewinding : 600 mm (23")
  • Maximum diameter at rewinding: 600 mm (23")
  • Maximum speed: 350 m/min (1,148 ft./min)


Converting MACHINERY for Shrinking Sleeve




SHRINKING SLEEVE FORMING MACHINE

Converting machine for shrinking sleeves. Compact design and easy to operate machine that runs with a wide range of plastic films such as PVC, PET, PETG, OPS and PLA.

Options:
  • Longitudinal perforating system, Alignment system.
  • Monitoring system for the width of the sleeve with an alarm system
  • UV lamp and adhesive application sensor
  • Inflatable shafts for different diameters
Technical characteristics:
  • Unwinding diameter: 800 mm (31.5")
  • Rewinding diameter: 600 mm(24")
  • Maximum width at unwinder: 600 mm (24")
  • Maximum width of formed sleeve: 254 mm (10")
  • Minimum width of formed sleeve: 32 mm (1.26")
  • Speed: 500 m/min (1,640 ft./min)

TURRET TYPE SYSTEM FOR UNWINDER AND WINDER FOR SHRINKING SLEEVE FORMING MACHINE

Turret type machine to avoid stopping the formation process of the shrinking sleeve. It allows automatic changes to the unwinder and winder.

Technical characteristics:
  • Unwinding maximum diameter: 600 mm (24")
  • Unwinding maximum weight: 600 mm (24")
  • Maximum speed: 500 m/min (1,640 ft./min)
  • Maximum speed for change to rolls: 250 m/min (820 ft./min)

SLEEVE CUTTING MACHINE

Cutter machine for shrinking sleeves, maximum productivity of 400 cuts per minute. Die-cutting system for transversal perforation.

This machine runs with a wide range of plastic film such as PVC, PET, PETG, OPS and PLA.

Optional
Optional Trimming system, edge suction, chucks for different diameter cores (3") and inspection system through a video camera or stroboscope.
Technical characteristics:
  • Unwinding diameter : 600 mm (24")
  • Rewinding diameter: 600 mm (24")
  • Max width: 600 mm (24")
  • Max speed: 350 m/min (1,148 ft..../min)
  • Max weight of roll: 45 kg (99 lb.)

NARROW INSPECTION MACHINE

This is a Rewinder to inspect printed rolls and shrinking sleeves such as PVC, PET, PETG, OPS & PLA. Reversible machine.

Optional
Trimming system, edge suction, chucks for different diameter cores (3") and inspection system through a video camera or stroboscope.
Technical characteristics:
  • Unwinding diameter : 600 mm (24")
  • Unwinding diameter : 600 mm (24")
  • Rewinding diameter: 600 mm (24")
  • Max width: 600 mm (24")
  • Max speed: 350 m/min (1,148 ft..../min)
  • Max weight of roll: 45 kg (99 lb.)

COMPACT DUPLEX SLITTER REWINDER

This machine cuts and rewinds plastic film and laminated material. It produces excellent finished rolls. differential shafts. control system and aligning system. Tension control by ultrasonic diameter sensor and vector motors.

Materials:
*Cellophane *PET *PE *PVC *BOPP *Laminated material *label
Technical characteristics:
  • Unwinding diameter: 1,000mm (39")
  • Rewinding diameter : 600 mm (23")
  • Material width: 1,300 mm (51")
  • Operating speed: 500 m/min (1,640 ft./min)
